PM6530A can set upper and lower limit alarm: when the measured value is greater than the ambient temperature + HAL value or less than the ambient temperature + LAL value, the red indicator will be on. PM6530 series are colorful display and non-contact infrared thermometer that allows you to measure the temperature of the objects by detecting their infrared energy. It is compact in size, light in weight and convenient to carry. Handheld infrared thermometer is used for non-contact measurement of object temperature 12 points form a circular measurement zone at the ratio of D:S=12:1, giving the more precise data.
Color Display
Laser Target Pointer (630nm~670nm): Circle
D:S=12:1
Emissivity: 0.10~1.00
Spectral Response: 8~14um
Temperature
Response Time:＜0.5s
IRT Temperature: -50°C~300°C,-58°F~572°F
Temperature Bridge Alarm (Red/Yellow/Green LED)
HOLD
Back Light
Auto Power Off
Low Battery Indication
MAX
| SPECIFICATION | RANGE | ACCURACY |
| IRT Temperature | -50～300℃ | ±（1.5%+2℃） |
| -58℉～572℉ | ±（1.5%+4℉） | |
| FEATURE | ||
| Color Display | √ | |
| Laser Target Pointer（630nm-670nm） | √ | |
| D:S=12:1 | √ | |
| Emissity：0.1～1.00 | √ | |
| Spectral Response：8～14um | √ | |
| Response Time：＜0.5S | √ | |
| Auto Power Off：15S | √ | |
| ℃/℉ | √ | |
| Temperature Bridge Alarm（Red/Yellow/Green LED） | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| Max Value | √ | |
| BackLight | √ | |
| GENERAL | ||
| Power Supply | 9V 6F22 Battery | |
| Product Size | 163mm×101mm×48mm | |
| Net weight | 165g(batteries are not included） | |
| Gross weight | 327g | |
| Safty Rating | EN61326,EN60825 | |
| Package（PCS/carton） | 30 pcs | |
| Color Box Size | 190mm×120mm×60mm | |
| Carton Size | 400mm×320mm×380mm | |
| G.W | 10.8kg | |
| Users Manual | 6F22 9V Battery |
