PM6519C is colorful display and non-contact infrared thermometer that allows you to measure the temperature of the objects by detecting their infrared energy. Multipurpose for cooking, refrigeration, automotive, air conditioning, HVAC and other households. Besides, it's also used in industrial, outdoor, indoor and other places. Larger objects may cause larger temperature measurement distance; for smaller objects, the measurement distances must be close. The ratio of measurement distance to the measured target is 12 : 1.
Color Display
Laser (630nm~670nm)
D:S=12:1
Emissivity: 0.10~1.00
Spectral Response: 8~14um
Temperature
Response Time: <0.5s
IRT Temperature
Ambient Temperature
Temperature Bridge Alarm (Red/Yellow/Green LED)
HOLD
Back Light
Auto Power Off
Low Battery Indication
| SPECIFICATION | RANGE | ACCURACY |
| IRT Temperature | -50～0℃（ -58℉～32℉） | ±3℃/6℉ |
| 0～550℃（32℉～1022℉ ） | ±（1.5%+2℃/4℉） | |
| Ambient Temperature | -10～0℃/45℃～60℃ | ±1.5℃ |
| 14～32℉/113～140℉ | ±3.0℉ | |
| 0～45℃ | ±1.0℃ | |
| 32～113℉ | ±2.0℉ | |
| Ambient Humidity | ±4.0%RH（20%～80%） | |
| ±5.0%RH(0%～20%,80%～99%) | ||
| FEATURE | ||
| Color Display | √ | |
| Laser Target Pointer（630nm-670nm） | √ | |
| D:S=12:1 | √ | |
| Emissity：0.1～1.00 | √ | |
| Spectral Response：8～14um | √ | |
| Response Time：＜0.5S | √ | |
| Auto Power Off：30S | √ | |
| ℃/℉ | √ | |
| Ambient Temperature | √ | |
| Ambient Humidity | √ | |
| Temperature Bridge Alarm（Red/Yellow/Green LED） | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| Max Value | √ | |
| BackLight | √ | |
| GENERAL | ||
| Power Supply | 1.5V×2AAA Batteries | |
| Product Size | 146mm×90mm×44mm | |
| Net weight | 113g(batteries are not included） | |
| Gross weight | 203g | |
| Safty Rating | EN61326,EN60825 | |
| Package（PCS/carton） | 40 pcs | |
| Color Box Size | 165mm×110mm×53mm | |
| Carton Size | 560mm×350mm×246mm | |
| G.W | 9.2kg | |
| Users Manual | 6F22 9V Battery |
