PM6501 is a portable digital thermometer. It has stable performance, high precision, low power consumption, novel structure. Safe and reliable, it’s an ideal measuring instrument for the majority of users. TP - 01 K type thermocouple probe with plug. It is a speeding reaction bead thermoelectric coupling, generally applicable to many fields. Range: - 50 - 750 Deg.C / - 58 - 1382 Deg.F. When not connected to a thermocouple or thermocouple open, the LCD will display the environment temperature.
Display: 2000 Counts
Thermocouples Type: K-type
Data Hold
Resolution: 0.1°C/1°C/0.1°F/1°F
| SPECIFICATION | RANGE | RESOLUTION | ACCURACY |
| Temperature | –50℃～–20℃ | 0.1℃ | ±6℃ |
| –20℃～-0.0℃ | 0.1℃ | ±3℃ | |
| 0.0℃～200℃ | 0.1℃ | ±（1.0%+2℃） | |
| 200℃～500℃ | 1.0℃ | ±（1.0%+2℃） | |
| 500℃～750℃ | 1.0℃ | ±（1.0%+3℃） | |
| –58℉～–4℉ | 0.1℉ | ±8℉ | |
| –4℉～32℉ | 0.1℉ | ±5℉ | |
| 32℉～200℉ | 0.1℉ | ±（1.0%+4℉） | |
| 200℉～932℉ | 1.0℉ | ±（1.0%+4℉） | |
| 932℉～1382℉ | 1.0℉ | ±（1.0%+5℉） | |
| FEATURE | |||
| Display | 2000 counts | ||
| Thermocouples Type | √ | ||
| Data Hold | √ | ||
| Resolution | 0.1℃/1℃/0.1℉/1℉ | ||
| GENERAL | |||
| Power Supply | 1.5V×2AAA Batteries | ||
| Product Size | 128mm×61mm×25mm | ||
| Net weight | 93g(batteries are not included） | ||
| Gross weight | 154g | ||
| Safty Rating | CE RoHS | ||
| Package（PCS/carton） | 90 pcs | ||
| Color Box Size | 142mm×88mm×35mm | ||
| Carton Size | 445mm×370mm×290mm | ||
| G.W | 14.7kg | ||
| K Type Thermocouple | Users Manual | 2*1.5V AAA batteries |
