This Smart AC/DC Clamp multimeter is an innovative, which is breaking through the traditional clamp Multimeter type. It is a revolutionary product of measurement tools, which is a unique type prior to the world's major instrument manufacturers. Its designed is according to EN61010-1, EN61010-2-032, and CAT.III600V Concerning Safety Requirements.
Display: 6000 Counts
RANGE: Auto
Continuity
Resistance: 6kΩ/60kΩ/600kΩ/6MΩ/10MΩ
V/Ω/A Auto Scan
Frequency (Clamp): 1kHz
Frequency (Voltage): 1kHz
Data Hold
Back Light
NCV
Low Battery Indication
Auto Power Off
Dual Display
| SPECIFICATION | RANGE | ACCURACY |
| DC Voltage | 6V/60V/600V | ±（0.5%+3） |
| AC Voltage | 6V/60V/600V | ±（0.8%+5） |
| DC Current | 60A/600A | ±（3.0%+10） |
| AC Current((40-65Hz) ) | 60A/400A | ±（2.5%+8） |
| 400A～600A | ±（3.0%+10） | |
| Resistance | 6KΩ/60KΩ/600KΩ/6MΩ/10MΩ | ±（0.8%+3） |
| Frequency | 40Hz～1000Hz | ±（1.0%+5） |
| Capacitance | ||
| ℃/℉ | ||
| DCuA | ||
| FEATURE | ||
| Display | 6000 Counts | |
| Auto range | √ | |
| Continuity | √＜50Ω | |
| V/Ω/A Auto Scan | √ | |
| Frequency(Clamp) | 1KHz | |
| Frequency(Voltage)1KHz | 1KHz | |
| Temperature | ||
| LPF（1KHz-3dB) | ||
| LowZ | ||
| Capacitance | ||
| BackLight | √ | |
| NCV | √ | |
| Low Battery Indication | √ | |
| Auto Power off | √ | |
| Dual Display（ACV+ Freq，ACA+ Freq ） | √ | |
| GENERAL | ||
| Power Supply | 2×1.5V AAA Batteries | |
| Product Size | 189mm×64mm×32mm | |
| Jaw Size | φ24mm | |
| Net weight | 177g(batteries are not included） | |
| Gross weight | 369g | |
| Safty Rating | EN61010-1,EN61010-2-033,EN61326,CAT.Ⅲ600v | |
| Package（PCS/carton） | 30pcs | |
| Color Box Size | 202mm×113mm×45mm | |
| Carton Size | 425mm×250mm×360mm | |
| G.W | 12.1kg | |
| Test Leads | Users Manual | 2*1.5V AAA batteries |
