PM2028S Smart AC/DC Clamp multimeter is an innovative, which is breaking through the traditional clamp Multimeter type. The meter can preform measurements of AC/DC valtage and current resistance, frequency, capacitance, etc. Specially, it has Max. and Min. value hold function.It is an ideal multi-function instrument with scores of pracrical applications for professional ,workshop, schools, hobby and home use.Specially, it has Max. and Min. value hold function. Its' designed is according to EN61010-1, EN61010-2-032, and CAT.III600V Concerning Safety Requirements.
Display: 6000 Counts
Continuity
Resistance: 6kΩ/60kΩ/600kΩ/6MΩ/10MΩ
V/Ω/A /Cap Auto Scan
Frequency (Clamp): 1kHz
Frequency (Voltage): 1kHz
Data Hold
Back Light
NCV
Low Battery Indication
Auto Power Off
Dual Display
| SPECIFICATION | RANGE | ACCURACY |
| DC Voltage | 6V/60V/600V | ±（0.5%+3） |
| AC Voltage | 6V/60V/600V | ±（0.8%+5） |
| AC Current | 60A/600A/1000A | ±（2.5%+8） |
| Resistance | 6KΩ/60KΩ/600KΩ/6MΩ/10MΩ | ±（0.8%+3） |
| Frequency | 40Hz～1000Hz | ±（1.0%+5） |
| Duty | ||
| Capacitance | ||
| ℃/℉ | ||
| LowZ | ||
| FEATURE | ||
| Display | 6000 Counts | |
| Analogue Bar Graph | ||
| Auto and Manual Range | ||
| True RMS | ||
| Data Hold | √ | |
| WorkLight | √ | |
| NCV | √ | |
| Relative Measurement | ||
| Continuity | ||
| BackLight | √ | |
| VFD | ||
| Auto Power off | √ | |
| LPF | √ | |
| Dual Display | √ | |
| V/Ω/A/Cap Auto Scan | √ | |
| GENERAL | ||
| Power Supply | 3×1.5V AAA Batteries | |
| Product Size | 247mm×84mm×40mm | |
| Jaw Size | φ35mm | |
| Net weight | 314g(batteries are not included） | |
| Gross weight | 595g | |
| Safty Rating | EN61010-1,EN61010-2-033,EN61326,CAT.Ⅲ600v | |
| Package（PCS/carton） | 20 pcs | |
| Color Box Size | 270mm×126mm×56mm | |
| Carton Size | 590mm×280mm×280mm | |
| G.W | 12.9kg | |
| Test Leads | Users Manual | 3*1.5V AAA batteries |
