The PM2116S is designed to automatically select measurement functions and measuring ranges. This intelligent AC/DC Clamp Meter is an innovative product, which has breaks through the traditional clamping universal meter and become a high-tech measuring tool.The product can display the Current Frequency while measuring the Current/Voltage, and they will be displayed on its display screen.It has Low Pass Filter, Peak Value Measurement, Non Contact Voltage detection, Backlight display,Data Hold function. Users can complete the above functions at any time whenever the Multimeter been boot up. Users does not need to make any gear changes during the measurement without fear that if it will be burnt by the wrong operation. The instrument is designed to automatically select measurement functions and measuring ranges.
Display: 6000 Counts
Auto Range
Continuity
Resistance
V/Ω/A Auto Scan
Frequency (Clamp): 1kHz
Frequency (Voltage): 1kHz
Data Hold
Back Light
NCV
| SPECIFICATION | RANGE | ACCURACY |
| DC Voltage | 0.5～600V | ±（0.5%+3） |
| DC Current | 6A/60A/100A | ±（3.0%+8） |
| AC Voltage | 1.0～600V | ±（0.8%+5） |
| AC Current | 6A/60A/100A | ±（2.5%+8） |
| Resistance | 0～6kΩ | ±（0.8%+3） |
| Frequency | 40Hz～1000Hz | ±（1.0%+5） |
| FEATURES | ||
| Display | 6000 counts | |
| Auto range | √ | |
| Continuity | √＜50Ω | |
| V/Ω/A Auto Scan | √ | |
| Frequency(Clamp) | √ | |
| Frequency(Voltage) | √ | |
| Data Hold | √ | |
| BackLight | √ | |
| NCV | √ | |
| GENERAL | ||
| Power Supply | 2×1.5V AAA Batteries | |
| Net weight | Approx.115g(batteries are not included） | |
| Gross weight | 250g | |
| Product Size | 158mm×55mm×29mm | |
| Jaw Size | φ20mm | |
| Safety Rating | EN61010-1,EN61010-2-033,EN61326,CAT.Ⅲ600v | |
| Package（PCS/carton） | 60 pcs | |
| Color Box Size | 174mm×100mm×32mm | |
| Carton Size | 370mm×380mm×325mm | |
| G.W | 16kg | |
| Test Leads | Users Manual | 2*1.5V AAA batteries |
