This AC Digital Flexible Clamp Meter is an innovative, with Max current 3000A which is breaking through the traditional clamp Meter. Current Measurement can display the current frequency simultaneously,as well as the Voltage measurement . Current and Voltage can be measured the same time with the Voltage and current display Features with low-pass filtering, the peak-peak measurement, NCV non-contact voltage detection, backlight display, data lock, All above functions can be completed whenever the product has been boot up . no need any gear conversion, never have to worry it will be burned by mistaken operation.DC voltage measurement.
Display: 6000 Counts
True RMS
Data Hold
Work Light
Back Light
| SPECIFICATION | RANGE | ACCURACY |
| DC Voltage | 6V/60V/600V | ±（0.8%+3） |
| AC Voltage（45～65Hz) | 6V/60V/600V | ±（1.2%+3） |
| AC Voltage（40～2000Hz) | 6V/60V/600V | ±（2.0%+5） |
| AC Current(40～65Hz) | 60A/600A | ±（1.5%+5）（＜10A：±（2.0%+10）） |
| 3000A | ±（2.0%+5 | |
| AC Current(65～200Hz) | 60A/600A | ±（2.5%+5） |
| 3000A | ±（3.0%+5） | |
| AC Current(200～1000Hz) | 60A/600A/3000A | ±（3.0%+5）＞1000A No verification |
| Frequency | 40Hz～1000Hz | ±（0.5%+2） |
| Resistance | 6KΩ/60KΩ/600KΩ/6MΩ | ±（1.0%+3） |
| FEATURE | ||
| Display | 6000 Counts | |
| True RMS | √ | |
| Data Hold | √ | |
| BackLight | √ | |
| Work Light | √ | |
| GENERAL | ||
| Power Supply | 3×1.5V AAA Batteries | |
| Product Size | 324mm×178mm×30mm | |
| Jaw Size | φ150mm | |
| Net weight | 178g(batteries are not included） | |
| Gross weight | 456g | |
| Safty Rating | EN61010-1,EN61010-2-033,EN61326,CAT.Ⅳ600v | |
| Package（PCS/carton） | 20 pcs | |
| Color Box Size | 235mm×140mm×50mm | |
| Carton Size | 495mm×270mm×30mm | |
| G.W | 10.2kg | |
| 3*1.5V AAA Batteries | Users Manual |
English
