The PM8200B is a high-precision, versatile tool designed for professional use, capable of measuring DC voltage up to 1500V and AC voltage up to 1200V. With additional features like 1MΩ resistance measurement, dual red and white backlights for enhanced visibility, flexible buzzer modes, and an IP65 waterproof and dustproof rating, the PM8200B ensures reliable performance in any environment. This robust and user-friendly tester is essential for electricians and technicians seeking accuracy and durability in their electrical testing equipment.
AUTO
IP Degree: IP65
Back Light
Phase Sequence Test: Three-Phase AC Voltage Range: 150V~400V, Frequency 50Hz~60Hz
Floodlight
Automatic Shutdown
Continuity
| SPECIFICATION | RANGE | ACCURACY |
| DC Voltage | 200V/1500V | ±（1.0%+3） |
| AC Voltage (TRMS) | 200V/1200V | ±（1.0%+3）＜500Hz |
| 200V/1200V | ±（1.5%+8）＞500Hz | |
| Resistance | 1MΩ | ±（5.0%+5） |
| FEATURES | ||
| AUTO | √ | |
| Backlight | √ | |
| IP Degree | IP65 | |
| Phase Sequence Test | Three-phase AC voltage range : 150V～400V,frequency 50HZ～60HZ | |
| Floodlight | √ | |
| Automatic Shutdown | √ | |
| Continuity | √ | |
| GENERAL | ||
| Power Supply | 2×1.5V AAA Batteries | |
| Net weight | Approx.317g(batteries are not included） | |
| Gross weight | ||
| Product Size | 290mm×80mm×34mm | |
| Safety Rating | EN61326,EN60529,CAT.IV 600V,CAT.Ⅲ 1000V | |
| Package（PCS/carton） | ||
| Color Box Size | ||
| Carton Size | ||
| G.W | ||
| Users Manual | 2*1.5V AA batteries |
