Specifications | Range | Frequency | Accuracy |
DC Voltage | 300mV | ±(0.1%+5) | |
3V/30V/300V | ±(0.05%+5) | ||
1000V | ±(0.1%+5) | ||
DC Current | 300µA/3mA/30mA/300mA | ±(0.5%+10) | |
10A | ±(1.2%+50) | ||
AC Voltage | 300mV | 40Hz-1KHz | ±(1.0%+10) |
1KHz-10KHz | ±(1.5%+30) | ||
3mV | 40Hz-1KHz | ±(0.8%+10) | |
1KHz- 10KHz | ±(1.2%+50) | ||
40Hz-100Hz(LPF) | ±(1.2%+50) | ||
30V | 40Hz-1KHz | ±(0.8%+10) | |
1KHz-10KHz | ±(1.2%+50) | ||
40Hz-100Hz(LPF) | ±(1.8%+50) | ||
300V | 40Hz-1KHz | ±(0.8%+10) | |
1KHz- 10KHz | ±(2.0%+50) | ||
40Hz-100Hz(LPF) | ±(2.0%+50) | ||
1000V | 40Hz-1KHz | ±(1.2%+10) | |
1KHz- 10KHz | ±(3.0%+50) | ||
40Hz-100Hz(LPF) | ±(3.0%+50) | ||
AC+DC Voltage | 3V/30V/300V/1000V | 40Hz-500Hz | ±(1.8%+70) |
AC Current | 300µA | 40Hz-1KHz | ±(0.8%+10) |
1KHz-10KHz | ±(3.0%+50) | ||
3mA | 40Hz-1KHz | ±(0.8%+10) | |
1KHz-10KHz | ±(3.0%+50) | ||
30mA | 40Hz-1KHz | ±(1.2%+10) | |
1KHz-10KHz | ±(3.0%+50) | ||
300mA | 40Hz-1KHz | ±(1.2%+10) | |
1KHz-10KHz | ±(3.0%+50) | ||
10A | 40Hz-1KHz | ±(1.2%+10) | |
1KHz-10KHz | ±(3.0%+50) | ||
Resistance | 300Ω/3KΩ/30KΩ/300KΩ | ±(0.5%+10) | |
3MΩ | ±(0.8%+10) | ||
30MΩ | ±(1.5%+10) | ||
300MΩ | ±(3.0%+10) | ||
Capacitance | 30nF/300nF/3nF/30µF | ±(3.0%+5) | |
300µF | ±(4.0%+5) | ||
3mF | ±(4.0%+5) | ||
30mF | ±(10.0%+5) | ||
300mF | ±(20.0%+5) | ||
Frequency | 10Hz-300MHz | ±(0.01%+5) | |
Duty | 0.1%~99.9% | ±(2.0%+5) | |
Feature | |||
Display: 30000 Counts | Low Battery Indication | ||
Auto Power Off | Relative Measurement | ||
USB Interface | MAX/MIN | ||
Continuity | Back Light | ||
Data Hold | Diode | ||
LPF | hFE | ||
General | |||
Power Supply: 4×1.5V AA | |||
Size: 204(L)×94(W)×57(H)mm | |||
Safety Rating: EN61010-1,EN61010-2-033,EN61326,CAT.Ⅲ 1000V/CAT.Ⅳ 600V |
PM8237 is a high-resolution digital multimeter that has been carefully developed over years. The product has a high-definition wide-angle large screen and 30000 counts display which is more convenient for users to obtain accurate readings. This multimeter can not only measure AC and DC voltage, AC and DC current, resistance, capacitance and frequency, but also has USB data transmission, diode, triode test and other functions.
