10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption

10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption
10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption 10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption

Large Image :  10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption

Product Details:
Place of Origin: China
Brand Name: PEAKMETER
Certification: CE
Model Number: PM8236B
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Product Size 204 x 93 x 57mm Product Weight Approx. 580g
Delivery Time: 5-40 work days
Payment Terms: T/T
Supply Ability: 150,000 Pcs Per Month

10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption

Description
Product Name: Auto Range Digital Multimeter Measuring Resistance: 0~60MΩ
Measuring Voltage: 0~1000V Measuring Current: 0~10A
Measuring Capacitance: 0-100mF Temperature: -20 ℃~1000 ℃
High Light:

auto electrical tester multimeter

,

true rms digital multimeter

,

handheld auto range digital precision multimeter

Auto Range Hand - Held Digital Multimeter With Bluetooth Interface And LCD Display



Features



The instrument is a hand-held intelligent multifunction measurement instrument, integrating noise, illuminance, humidity, temperature and digital multimeter into one. With large LCD digital display (three sets of data display) and backlight, it’s easy for user to read, with overload protection and battery under-voltage indication. Whether for professionals, factories, schools, amateurs or family use, it’s an ideal multi-funtional instrument.

  • Manual range and automatic range: the instrument is equipped with manual and automatic range. In automatic range mode, the instrument will select the best range for the input signal detected, so it is convenient that the users does not need to re-select range when changing the measuring signal.
  • The instrument is equipped with relative value measurement function. In this mode, the instrument display value = actual value-set reference value.
  • The instrument is equipped with maximum value, minimum value and maximum-minimum value hold function.
  • USB or Bluetooth interface function is set for the instrument, and you could upload instrument measurement data onto PC or mobile APP for displaying, recording and analysis via USB or Bluetooth.



Product Description



SPECIFICATIONS RANGE ACCURACY
DC Voltage 60mV/600mV/6V/60V/600V/1000V ±(0.7%+2)
AC Voltage 60mV/600mV/6V/60V/600V ±(0.8%+3)
750V ±(1.0%+3)
AC Current 600μA/6000μA/60mA/600mA ±(1.2%+3)
6A/10A ±(2.0%+10)
DC Current 600μA/6000μA/60mA/600mA ±(1.5%+3)
6A/10A ±(3.0%+10)
Resistance 600Ω/6kΩ/60kΩ/600kΩ/6MΩ ±(1.2%+5)
60MΩ ±(2.0%+5)
Capacitance 10nF/100nF/1000nF/10μF/100μF/1000μF/10mF ±(3.0%+3)
Frequency 10Hz/100Hz/1000Hz/10kHz/100kHz/1000kHz/10MHz ±(1.0%+5)
Duty 1%~99% ±3.0%
Temperature(℃/℉) -20℃~1000℃ ±(2.0%+2)
-4℉~1832℉ ±(2.0%+2)
FEATURE
Display 6000 Counts
Interface Bluetooth Interface
Auto and manual range
True RMS
Data hold
bargraph display
MAX/MIN
Relative Measurement
Continuity
Back light
Transistor
Diode test
GENERAL
Power Supply 4×1.5V AA Batteries
Weight Approx. 580g
Size 204mm×93mm×57mm
Safety Rating EN61010-1,EN61010-2-033, EN61326,CAT.Ⅲ 1000V



Detailed Images



10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption 0



10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption 1



10 Amp True Rms Digital Multimeter Bluetooth Interface Lower Power Consumption 2
